Range XXL
Download the documentation
Industrial ovens XXL are designed for easy loading of your products, no weight limit ! For all application of curing, polymerization, coating, preheating, heating, drying, vitrification, stabilization... on all types of products : prepregs, free-solvent paints and glues, molds, tools, glasses, compact powders, resins, metallic parts, electronic parts, elastomer… in any type of industrial environments. Max temperature :
200°C / 300°C
(option) 9 sizes : 1000, 1500, 1800, 2700, 3000, 4500, 8000, 12000, 15000 liters.
The best of industrial oven
The internal sheets are made of electrogalvanized steel. The external sheets are also made of electrogalvanized steel coated with white and blue epoxy paints. Insulation is constituted with glass wool. The optimized insulation and no thermal bridge between the inner and outer casings enable to minimize heat losses, to speed heating-up and to reduce surface temperatures. This allows an excellent thermal stability and a power consumption decrease. Up to the XXL02.7 model, ovens have a single door, hinges to the right. From the XXL03 model, ovens have a double-leaf door with an inner handle allowing an operator that has been accidently shut up in the oven to free. All control devices are located on the left side of the oven. You can pass different cables and probes through a Ø 20 mm access port with silicone cork located on the left side. The XXL ovens have been designed for a loading with trolley. The floor is a front-beveled thin sheet allowing an easy access.
An amazing temperature homogeneity
Thanks to their exclusive ventilation system and to their efficient heating system, our XXL ovens guarantee excellent temperature uniformity. Ventilation is forced convection. Our engineers studied ventilation thanks to a fluids simulation software. We guarantee the best heat distribution possible. The fan is located on the top of the oven. Working volume’s air is sucked by the impeller, is reheated by the heating system then is blown into the working volume from the back part on the whole width. Heating is ensured by heating elements, ideally placed in the air flow.
Air change system
The oven is equipped with an air change system composed of air inlet and outlet with adjustable flaps.
The C3030 temperature profiler
The FRANCE-ETUVES C3030 temperature controller is very accurate and particularly reliable. Measurement by PT100 or TCJ probe. Electronic PID temperature controller. Accuracy: 0.1°C. Color display, excellent visibility of temperatures. Functions : display of setpoint and measured temperature display (in percentage) of the heating power used date and time display Possibility of making 1 program with 8 steps: 4 programmable temperature ramps (°C/min) and 4 heating timer (max 99h59min) delayed start repeat loop monitoring of your current program (step and remaining time) pause or stop the program end of cycle buzzer PID adjustment possibility of adding a temperature correction at 2 distinct temperatures (offsets) RS485 modbus multipoint communication: allows to control several ovens on the same network
Protections for your oven and your products.
Stop fan and heating when the door is opened. An ajustable electronic thermostat (class 3.1 protection) protects your products. It measures the temperature in the volume, and supports the regulation in case of failure of the temperature controller. It stops heating until the temperature has dropped below the value of its setting. A mechanical thermostat with reset button (class 1 protection) protects the oven. It checks if the temperature rises unusually. Heating is then cut. In case of failure of the ventilation fan, the heating is stopped. Different visual alarms.
Model | XXL01 |
---|---|
Chamber volume: | 1000 litres |
Performances : | |
---|---|
Standard maximum temperature : | 200 °C |
Optional maximum temperature : | 0 °C |
Dimensions : | |
---|---|
Chamber volume: | 1000 litres |
Interior Dimensions (L x P x H) : | 1000 x 1000 x 1000 mm |
Exterior Dimensions (L x P x H) : | 1535 x 1559 x 1415 mm |
Power & Divers : | |
---|---|
Electrical Supply : | 400V ~3P 50Hz 20A |
Standard power 200 °C : | 12000 Watts |
Number of door(s) : | 1 |
Ventilation flow rate : | 1800 m3/hour |
Weight : | 500 kg |
Model | XXL01.5 |
---|---|
Chamber volume: | 1500 litres |
Performances : | |
---|---|
Standard maximum temperature : | 200 °C |
Optional maximum temperature : | 0 °C |
Dimensions : | |
---|---|
Chamber volume: | 1500 litres |
Interior Dimensions (L x P x H) : | 1000 x 1000 x 1500 mm |
Exterior Dimensions (L x P x H) : | 1580 x 1561 x 1974 mm |
Power & Divers : | |
---|---|
Electrical Supply : | 400V ~3P 50Hz 25A |
Standard power 200 °C : | 15000 Watts |
Number of door(s) : | 1 |
Ventilation flow rate : | 2500 m3/hour |
Weight : | 620 kg |
Model | XXL01.8 |
---|---|
Chamber volume: | 1800 litres |
Performances : | |
---|---|
Standard maximum temperature : | 200 °C |
Optional maximum temperature : | 0 °C |
Dimensions : | |
---|---|
Chamber volume: | 1800 litres |
Interior Dimensions (L x P x H) : | 1000 x 1000 x 1800 mm |
Exterior Dimensions (L x P x H) : | 1556 x 1559 x 2283 mm |
Power & Divers : | |
---|---|
Electrical Supply : | 400V ~3P 50Hz 32A |
Standard power 200 °C : | 18000 Watts |
Number of door(s) : | 1 |
Ventilation flow rate : | 2500 m3/hour |
Weight : | 680 kg |
Model | XXL02.7 |
---|---|
Chamber volume: | 2700 litres |
Performances : | |
---|---|
Standard maximum temperature : | 200 °C |
Optional maximum temperature : | 0 °C |
Dimensions : | |
---|---|
Chamber volume: | 2700 litres |
Interior Dimensions (L x P x H) : | 1000 x 1800 x 1500 mm |
Exterior Dimensions (L x P x H) : | 1570 x 2362 x 2041 mm |
Power & Divers : | |
---|---|
Electrical Supply : | 400V ~3P 50Hz 40A |
Standard power 200 °C : | 21000 Watts |
Number of door(s) : | 1 |
Ventilation flow rate : | 3250 m3/hour |
Weight : | 850 kg |
Model | XXL03 |
---|---|
Chamber volume: | 3000 litres |
Performances : | |
---|---|
Standard maximum temperature : | 200 °C |
Optional maximum temperature : | 0 °C |
Dimensions : | |
---|---|
Chamber volume: | 3000 litres |
Interior Dimensions (L x P x H) : | 1500 x 1500 x 1500 mm |
Exterior Dimensions (L x P x H) : | 2056 x 2070 x 2136 mm |
Power & Divers : | |
---|---|
Electrical Supply : | 400V ~3P 50Hz 50A |
Standard power 200 °C : | 24000 Watts |
Number of door(s) : | 2 |
Ventilation flow rate : | 4000 m3/hour |
Weight : | 980 kg |
Model | XXL04.5 |
---|---|
Chamber volume: | 4500 litres |
Performances : | |
---|---|
Standard maximum temperature : | 200 °C |
Optional maximum temperature : | 0 °C |
Dimensions : | |
---|---|
Chamber volume: | 4500 litres |
Interior Dimensions (L x P x H) : | 1500 x 2000 x 1500 mm |
Exterior Dimensions (L x P x H) : | 2056 x 2570 x 2136 mm |
Power & Divers : | |
---|---|
Electrical Supply : | 400V ~3P 50Hz 50A |
Standard power 200 °C : | 27000 Watts |
Number of door(s) : | 2 |
Ventilation flow rate : | 4000 m3/hour |
Weight : | 1085 kg |
Model | XXL08 |
---|---|
Chamber volume: | 8000 litres |
Performances : | |
---|---|
Standard maximum temperature : | 200 °C |
Optional maximum temperature : | 0 °C |
Dimensions : | |
---|---|
Chamber volume: | 8000 litres |
Interior Dimensions (L x P x H) : | 2000 x 2000 x 2000 mm |
Exterior Dimensions (L x P x H) : | 2559 x 2578 x 2665 mm |
Power & Divers : | |
---|---|
Electrical Supply : | 400V ~3P 50Hz 63A |
Standard power 200 °C : | 36000 Watts |
Number of door(s) : | 2 |
Ventilation flow rate : | 6000 m3/hour |
Weight : | 1300 kg |
Model | XXL12 |
---|---|
Chamber volume: | 12000 litres |
Performances : | |
---|---|
Standard maximum temperature : | 200 °C |
Optional maximum temperature : | 0 °C |
Dimensions : | |
---|---|
Chamber volume: | 12000 litres |
Interior Dimensions (L x P x H) : | 2000 x 3000 x 2000 mm |
Exterior Dimensions (L x P x H) : | 2505 x 3608 x 2797 mm |
Power & Divers : | |
---|---|
Electrical Supply : | 400V ~3P 50Hz 80A |
Standard power 200 °C : | 45000 Watts |
Number of door(s) : | 2 |
Ventilation flow rate : | 8000 m3/hour |
Weight : | 1800 kg |
Model | XXL15 |
---|---|
Chamber volume: | 15000 litres |
Performances : | |
---|---|
Standard maximum temperature : | 200 °C |
Optional maximum temperature : | 0 °C |
Dimensions : | |
---|---|
Chamber volume: | 15000 litres |
Interior Dimensions (L x P x H) : | 2500 x 3000 x 2000 mm |
Exterior Dimensions (L x P x H) : | 2900 x 3607 x 2855 mm |
Power & Divers : | |
---|---|
Electrical Supply : | 400V ~3P 50Hz 100A |
Standard power 200 °C : | 54000 Watts |
Number of door(s) : | 2 |
Ventilation flow rate : | 12000 m3/hour |
Weight : | 2500 kg |
Range XXL | XXL01 | XXL01.5 | XXL01.8 | XXL02.7 | XXL03 | XXL04.5 | XXL08 | XXL12 | XXL15 | |
---|---|---|---|---|---|---|---|---|---|---|
Performances | ||||||||||
---|---|---|---|---|---|---|---|---|---|---|
Temperature range : | Ambient temperature + 20 °C à 200 °C | |||||||||
Standard maximum temperature : | 200 °C | |||||||||
Homogeneity at 105 °C : | ± °C | < 2.0 | < 2.0 | < 2.0 | < 2.0 | < 2.0 | < 2.0 | < 2.0 | < 2.0 | < 2.0 |
Chamber dimensions | ||||||||||
---|---|---|---|---|---|---|---|---|---|---|
Chamber volume: | dm3 | 1000 | 1500 | 1800 | 2700 | 3000 | 4500 | 8000 | 12000 | 15000 |
Width : | mm | 1000 | 1000 | 1000 | 1000 | 1500 | 1500 | 2000 | 2000 | 2500 |
Depth : | mm | 1000 | 1000 | 1000 | 1800 | 1500 | 2000 | 2000 | 3000 | 3000 |
Height : | mm | 1000 | 1500 | 1800 | 1500 | 1500 | 1500 | 2000 | 2000 | 2000 |
Exterior Dimensions | ||||||||||
---|---|---|---|---|---|---|---|---|---|---|
Exterior Chamber Volume : | m3 | 3.39 | 4.87 | 5.54 | 7.57 | 9.09 | 11.29 | 17.58 | 25.28 | 29.86 |
Width : | mm | 1535 | 1580 | 1556 | 1570 | 2056 | 2056 | 2559 | 2505 | 2900 |
Depth : | mm | 1559 | 1561 | 1559 | 2362 | 2070 | 2570 | 2578 | 3608 | 3607 |
Height : | mm | 1415 | 1974 | 2283 | 2041 | 2136 | 2136 | 2665 | 2797 | 2855 |
Shelves: | ||||||||||
---|---|---|---|---|---|---|---|---|---|---|
Delivered / Maximum : | - | - | - | - | - | - | - | - | - | |
Dimensions L / P : | mm | - | - | - | - | - | - | - | - | - |
Maximum weight / Total : | kg | - | - | - | - | - | - | - | - | - |
Other informations | ||||||||||
---|---|---|---|---|---|---|---|---|---|---|
Number of door(s) : | 1 | 1 | 1 | 1 | 2 | 2 | 2 | 2 | 2 | |
Window L / l (option) | mm | 350x550 | 400x800 | 400x800 | 400x800 | 180x350 (x2) | 180x350 (x2) | 400x800 (x2) | 400x800 (x2) | 400x800 (x2) |
Weight : | kg | 500 | 620 | 680 | 850 | 980 | 1085 | 1300 | 1800 | 2500 |
Electrical data | ||||||||||
---|---|---|---|---|---|---|---|---|---|---|
Standard power 200 °C : | Watts | 12000 | 15000 | 18000 | 21000 | 24000 | 27000 | 36000 | 45000 | 54000 |
Electrical Supply : | volts | 400V ~3P 50Hz 20A | 400V ~3P 50Hz 25A | 400V ~3P 50Hz 32A | 400V ~3P 50Hz 40A | 400V ~3P 50Hz 50A | 400V ~3P 50Hz 50A | 400V ~3P 50Hz 63A | 400V ~3P 50Hz 80A | 400V ~3P 50Hz 100A |
Reference | Image | Description |
---|---|---|
AG9013 | Data logger with 2 channels (software included) Saves the temperatures measured by 2 mobile sensors. Record temperatures measured by 2 mobile sensors. Box with magnetic fixing<br> Dimensions : 93.2 x 65.2 x 30.5 mm Weight: 115 g<br> Display : LCD screen 2 lines | ABS IP54<br> Communication PC : 1 micro-USB Power supply by battery AA lithium 3.6V<br> Tc entries : female connector micro-USB, thermocouples (K, J, T, N, S)<br> Recording from every 1s to 24h Autonomy: 4 years (for 1 measure every 15 monutes) Software and cable included |
|
AG9014 | Portable paperless recorder with graphical screen 4 channels Color graphical display for real monitoring of temperature changes. With USB and RJ45 plugs, and 4 connectors for mobile sensors. |
|
AG9015 | Portable paperless graphic recorder with 6 channels Full color screen display. Real monitoring of temperature changes. With USB and RJ45 plugs, and 6 connectors for mobile sensors. |
|
AG9016 | Thermocouple probe Length 3 m, with plug |
|
AG9034 | Console for oven process control system |
|
AG9035 | Insulation plate with access ramp Tu put under the oven. 8 mm height |
